ZH23
Category:ZH23 Series
Keywords:ZH23 Series Russian Standard Circular Connectors: Bayonet-style quick-lock mechanism, aluminum alloy housing with yellow-green anodized finish, brass contacts gold-plated. Features excellent vibration resistance, wide temperature tolerance, and reliable sealing. Aerospace and military-grade performance.
Details
The ZH23 series Russian standard circular connectors feature a bayonet quick-lock mechanism, an aluminum alloy shell with yellow-green anodized finish, and brass contacts with gold plating. They offer superior vibration resistance, wide temperature tolerance, and reliable sealing. These connectors are widely used in aviation, aerospace, defense, marine, and telecommunications applications.
Parameters:
Materials and Technical Specifications; Mechanical and Electrical Performance:
| connector type | Round Connector | shell_material | Aluminum alloy |
| coupling | Quick-lock bayonet | shell_material | Aluminum alloy |
| shell_material | Aluminum alloy | contact_material | Gold-plated Brass |
| shell_finished | Yellow-green anodized | contact_material | Gold-plated Brass |
| contact_material | Gold-plated Brass | temp_range | -55°C ~ +125°C |
| standard | Russian Standard | temp_range | -55°C ~ +125°C |
| temp_range | -55°C ~ +125°C | application | Aerospace/Defense/Marine/Telecommunications |
| protection | IP7 | application | Aerospace/Defense/Marine/Telecommunications |
| application | Aerospace/Defense/Marine/Telecommunications |
